STRIKE THE RIGHT BALANCE

MIDWEIGHT

Snowplow

BIG PERFORMANCE
SIZED RIGHT FOR YOUR TRUCK

Get pro performance without an ounce of wasted weight. The WESTERN® MIDWEIGHT snow plow features professional grade reinforcement to push the boundaries of “light commercial work.”

MIDWEIGHT™

Unique features

Previous Next

PLOW BLADE CONSTRUCTION

The sturdy 7' 6" moldboard is 27" tall and comes in 14-gauge powder coated steel or 1/4" high-density polyethylene.

The durable poly blade provides a slick surface for enhanced snow-rolling action and a maintenance-free surface. The steel blade features our high quality ULTRAFINISH powder coat surface.

Both feature a 70-degree attack angle for a clean scrape, and come standard with a high carbon steel cutting edge that reduces wear and extends the life of the blade.

Previous Next

STRUCTURAL REINFORCEMENT

Six vertical ribs and the exclusive WESTERN® POWER BAR provide unmatched structural reinforcement, delivering exceptional torsional strength and rigidity to eliminate blade twisting.

The high-strength steel base channel provides extra support along the bottom of the plow blade.

The 1" diameter pivot bolt secures the plow in place, ensuring proper alignment and reducing stress on the overall plow assembly.

Previous Next

RELIABLE HYDRAULICS

We manufacture our own hydraulic components to ensure the highest standards of quality and reliability, so that you get a hydraulics system that's not only fast and responsive, but that's built to last season after season.

Fully enclosed components are protected from the elements.

Previous Next

TRIP PROTECTION

The two-spring trip blade protects your snow plow and truck when striking hidden obstacles.

Elastomeric bumpers reduce jarring and soften the blade return when tripping occurs, to extend the life of your truck and plow.

UNIVERSAL FEATURES

NIGHTHAWK Headlamps

Available in both LED and Dual-Halogen models, NIGHTHAWK headlamps are engineered and tested for maximum light output, performance and durability to keep you ahead of the storm.

LED Headlamps - LEARN MORE

Dual-Halogen Headlamps - LEARN MORE

UltraMount® 2 Snowplow Mounting System

The UltraMount® 2 system is designed for fast and easy installation and removal using a simple mechanical system. It features a robust one-piece design and is 100% compatible with UltraMount® system mounts and electrical platforms.

Chain Lift System

The mechanical chain lift system offers a variety of performance and reliability advantages over a hydraulic system.

FLEET FLEX ELECTRICAL SYSTEM

The FLEET FLEX electrical system provides true fleet interchangeability. The same FLEET FLEX CabCommand hand-held or joystick control can operate any UltraMount® and UltraMount® 2 mounted plow on any truck at any time.

SECURITY GUARD Anti-Theft System

The exclusive WESTERN® SECURITY GUARD snowplow anti-theft system is a safe and secure way to electronically lock your snow plow when it is detached from your truck as a deterrent from theft.

CONTROL OPTIONS

Choose between a CabCommand hand-held control with push buttons or a joystick control, based on operator preference. For efficient, precise and intuitive blade control while plowing, both controls feature power “on” and “float” LED lights, backlighting for night operation, and plug-in connector for easy removal.

Isolation Module

This advanced snow plow light and electrical system features improved electrical pins in the harness for trouble-free connections. An underhood module improves system life and complies with OEM requirements. No toggle switch needed to change from vehicle to plow lights.

ULTRAFINISH BAKED-ON POWDER COAT

The ULTRAFINISH baked on powder coat with epoxy primer is standard on all WESTERN® plows, providing outstanding protection against wear and rust.

FEATURED ACCESSORIES

BACK DRAG EDGE

Ensure a clean scrape, every time, when you back drag. Angled to maximize back dragging, the WESTERN® back drag edge is constructed to be as rugged and durable as every other component of your plow. Easy to install and easy to use, a back drag edge is a key tool in any snowfighter's kit.

CURB GUARDS

Go right up to the edge with bolt-on curb guards. Protect the outer edge of your snow plow from wear when plowing along sidewalks and curbs. Made of cast metal, each curb guard effectively protects the outer edge of the plow.

SHOE KIT

Protect your MIDWEIGHT snow plow and the road. Ride above the uneven surfaces of gravel and dirt with plow shoes. The cast iron construction and shape ensures that your plow glides over gravel and dirt at the perfect height. Bolt-on shoe kit extends cutting edge and base angle life when plowing rocky or abrasive surfaces.

PRODUCT SPECIFICATIONS

Print
Models POWDER COATED STEEL POLY
Blade Width 7' 6" 2.29 m 7' 6" 2.29 m
Blade Height 27" 68.58 cm 27" 68.58 cm
Blade Gauge 14 1.98 mm ¼" Poly 6.40 mm
Trip Springs 2 2 2 2
Vertical Ribs 6 6 6 6
Lift Cylinder 1 ½" x 8" 3.81 cm x 20.32 cm 1 ½" x 8" 3.81 cm x 20.32 cm
Angling Rams 1 ½" x 10" 3.81 cm x 25.40 cm 1 ½" x 10" 3.81 cm x 25.40 cm
Plowing Width (Full Angle) 6' 6" 1.98 m 6' 6" 1.98 m
Approx. Weight* 540 lb 244 kg 532 lb 241 kg
Cutting Edge ⅜" x 6" 0.95 cm x 15.24 cm ⅜" x 6" 0.95 cm x 15.24 cm
Mount Type UltraMount® 2 UltraMount® 2 UltraMount® 2 UltraMount® 2

*Does not include vehicle mount. Please refer to the Quick Match program for specific vehicle applications.
